3 Legged Thing Arnie QD L-Bracket for Sony Alpha Cameras Copper

The 3 Legged Thing Arnie QD L-Bracket for Sony Alpha Cameras Copper is precision-engineered to perfectly fit more recent bodies like the A7 IV, A7R V, A7 III, A7R III, A7R IV, A7S II, A7S III, A9 II and A1.



3 Legged Thing Arnie QD L-Bracket for Sony Alpha Cameras Copper Summary

This Arca-Swiss compatible dedicated L-bracket has been designed to perfectly a variety of recent Sony cameras, including the A7 IV, A7R V, A7 III, A7R III, A7R IV, A7S II, A7S III, A9 II and A1 camera bodies.

The ARNIE L-bracket is precision-engineered from a single block of aerospace-grade magnesium alloy. This construction gives it excellent rigidity.  ARNIE gives users access to the battery door and side ports on all cameras. The cut-out in the side aspect allows rear screens to be opened either upright or tilted. and a further cut-out gives access to the camera strap lug.

ARNIE’s base features an integral QD (quick detach) port, for use with QD accessories. It also has a slot to attach camera straps, plus two 3/8”-16 screw threads with ¼”-20 adapters, for the attachment of accessory arms. The front of the L-bracket has a contoured lip, to perfectly form around the base of the camera.

3 Legged Thing have supplied a Peak Design v3 Capture compatible adapter in the box. This robust glass-reinforced nylon adapter allows users to use ARNIE with their v3 Capture clips.

• Arca-Swiss compatible quick release plate
• Dedicated L-bracket that fits Sony Alpha cameras, including A7 IV, A7R V, A7 III, A7R III, A7R IV, A7S II, A7S III, A9 II and A1
• QD (quick detach) port in the base for use with QD accessories
• Two 3/8″”-16 screw threads with 1/4″”-20 adapters for accessory attachment in base
• Full access to side ports and battery door
• Cut-out in vertical aspect allows use of flip screens
• Supplied with adapter and long 1/4″”-20 camera screw to enable compatibility with Peak Design Capture clip
• Strap attachment slot in the base
• Weight-saving cut-out in the base
• Available in 2 colours – Copper or Darkness

What’s In The Box

• ARNIE Dedicated Sony Alpha Arca-Swiss & QD compatible L-bracket
• Tool – double ended Hex Key
• Stagsden Stainless Steel 1/4″”-20  camera screw
• Peak Design Capture-compatible adapter plate with longer 1/4″”-20 pass-thru camera screw
• 3 Legged Thing Reusable Cable Tie

Specifications

Base Length	10.2 cm / 4″
Base Width	4.2 cm / 1.65″
Working base range	n/a
Vertical Aspect Height	8.5 cm / 3.35″
Vertical Aspect Width	4.2 cm / 1.65″
Shoe	38 mm / 1.5 ” Standard Arca-Swiss
Weight	95 g / 3.35 oz
Compatibility	For Sony Alpha Cameras
Camera Mounting Screw	1/4″-20
Material	Milled Magnesium Alloy
Warranty	5 Year Global Warranty
Box/Pack Dimensions	9.1 x 4.7 x 11 cm / 3.6 x 1.9 x 4.3″
Box/Pack Weight	150 g / 5.29 oz
Carton Dimensions	50.5 x 23.5 x 23 cm / 19.9 x 9.25 x 9″
Carton Gross Weight	7.18 kg / 15.8 lb
Carton Net Weight	4.91 kg / 10.8 lb
