Panasonic HC-X2 Camcorder

• Compact pro video camera with extensive connectivity and built-in 24.5mm wide to super telephoto zoom lens
• Broad range of video options including 4K60p (HEVC), 4K30p 4.2.2-10bit and super slow variable frame rate capture
• 1.0-type MOS sensor with 15-megapixel effective resolution and wide dynamic range of 13-stops using VLOG
• 4K high-precision AF and new Face detection AF/AE as well as 5-Axis hybrid OIS delivers smooth, sharp footage
• Wide range of connectivity options supporting studio and field recording, pro audio and live-streaming

Key Features

• 1.0-type MOS sensor with 15-megapixel effective resolution
• Built-in wide angle Panasonic lens with 20x optical zoom (24.5-490mm full-frame equivalent)
• New Face detection AF/AE and 4K high-precision AF
• Stabilisation from 5-Axis hybrid OIS
• Capture 4K60p (High Efficiency Video Coding) with 4K60p 4.2.0-10bit, 4K30p 4.2.2-10bit and 120 Slow 2-60 fps VFR
• Wide dynamic range with HLG 13-stop VLOG
• Extensive connectivity through USB-C 3.1, built-in WiFi, a new Mic Holder and 3G SDI output
• Pro 24bit PCM audio with 2x XLR IN
• Timecode IN/OUT, built-in 1/4, 1/16, 1/64 ND filter
• Live-streaming in H.264/MPEG-4 AVC FHD

Panasonic HC-X2 Camcorder Summary

The Panasonic HC-X2 Camcorderis a 4K ready , with a host of features for broadcast pros, solo filmmakers and production teams. A built-in wide angle  with 20x optical zoom captures an equivalent full-frame zoom range of 24.5-490mm and harnesses new Face detection AF/AE with 4K high-precision AF.

The HC-X2 camcorder records a range of high-quality video and dual codecs for 4K60p (HEVC), 4K60p 4.2.0-10bit, 4K30p 4.2.2-10bit and a wide 13-stop dynamic range when shooting HLG VLOG. With 3G SDI output, ethernet, Timecode IN/OUT and built-in WiFi this model includes connectivity which is ideal for the studio, team productions and fieldwork. You can also capture pro-quality 24bit PCM audio using two XLR inputs to add an .

Panasonic HC-X2 UHD 4K Professional Camcorder in More Detail

Integrated 20x optical zoom lens

Both the HC-X2 and , which was released simultaneously, feature an integrated wide angle 24.5mm lens with 20x optical zoom, which provides an equivalent 24.5-490mm range. You can zoom to a maximum of approx. 32x FHD (24x UHD), while maintaining high-definition image quality.

Triple manual rings and ND filter

The Panasonic HC-X2 Camcorder features triple manual rings on the lens barrel for Zoom, Focusand Iriscontrol. These manual functions ensure professional operation with fast and intuitive camera work.

You can also set focus ring operation and movement with Linear and Non Linear adjustment, and rotation angle when Linear is set.

Convenient built-in 1/4, 1/16, 1/64, or clear ND filters allow you to adjust according to shooting conditions.

5-Axis Hybrid O.I.S. for UHD and FHD

Electronic Image Stabilisation operates iIn addition to Optical Image Stabilisation in both UHD/FHD modes, detecting and correcting handshake in 5-axis, including rotational blurring. This provides powerful correction in a variety of unstable shooting conditions including when capturing low-angle and high-angle shots. Drive wear is reduced through the use of a Ball O.I.S. System which is designed to reduce the effects of minor movements.

Choose from:

• NORMAL (standard)
• STABLE (effective for fixed-frame shooting)
• PAN/TILT (effective in panning and tilting)

High-Speed, high-precision AF technology in 4K

Panasonic AF performance is accurate and quick even in various 4K recording situations with great tracking performance and stability. Face detection AF quickly captures subjects even when they first enter the frame and subjects stay in focus even when obstacles pass across.

High-quality and versatile recording formats

The HC-X2 Camcorder offers numerous recording modes and formats including 422 LongGOP, 4:2:2 10Bit 30p and 4:2:0 10Bit 60p.

VFR (2-60fps) super slow-motion recording

Record from 2 to 60 fps with 10-step VFR (Variable Frame Rate) to create slow-motion effects and quick motion effects. HD mode delivers a super-slow motion effect with a maximum 120 fps (59.94 Hz) or 100 fps (50 Hz). It supports high-quality 10-bit recording in FHD mode using the full sensor area, even at high frame rates.

High dynamic range recording (HLG)

The X2 introduces Hybrid Log Gamma for HDR video recording to capture natural, true-to-life images without compromising gradation to simultaneously render brighter and darker areas.

13-stop V-log / V-Gamut

V-Log/V-Gamut is supported, which is the same as found in Panasonic VARICAM and . The wide dynamic range provides a wide colour gamut, which can be readily drawn-out in post production.

IR (Infrared) shooting in darkness

Capture scenes at night, animals and events in darkness before lights are turned on, using a built-in IR Cut Filter, which can be turned ON/OFF. Panasonic recommends 850-nm wavelength light.

Simultaneous SDI/HDMI output

Output to a  over HDMI whilst simultaneously to  such as a Live switcher in UHD 422 10-bit over HDMI and FHD 422 10-bit over SDI.

Simultaneous display on LCD monitor and EVF

Enjoy two previews with a monitor which can be constantly displayed even while viewing with the EVF on the Panasonic HC-X2 Camcorder. The daytime viewable 3.5-inch 2,760K-dot LCD offers Touch Operation with quick focusing and selfie shooting mode with 180º rotation. The EVF (with included eyecup) delivers 1,769K-dot-equivalent colour and can be tilted for convenience.

Dual SD memory card slots

With two  slots unlimited relay recording is achieved by changing SD cards, and provides various recording systems for high reliability. Images can be recorded simultaneously in 4K/UHD + FHD (50 M) or FHD (100 M or higher) + FHD (8 M) for an efficient workflow. Data can be recorded continuously by automatically switching from Slot 1 to Slot 2. Options include:

• Dual Codec Recording
• Unlimited Relay Recording
• Simultaneous Recording
• Background Recording

Usability supports pro workflows

A number of features are included to support uninterrupted shooting including a cable clamp on the hand belt, which prevents cable catching. Camera settings can be saved onto SD card to restore settings and multi-cam set-ups. A new mic holder supports one-touch opening and closing and a fast zoom lever on the grip changes speed according to your input.

High resolution 48kHz/24-bit PCM audio recording

2 x XLR Audio Inputs offer switchable 48-V phantom power supply/MIC/LINE with high resolution sound from 24-bit linear PCM recording in MOV mode. There are also two volume controls catering for each channel, an OSD level meter and headphone jack.

Long battery life

Enjoy a range of shooting times up to approximately 7h 40 minutes from a single  and compatibility with:

Pro video assist functions

Panasonic has included a number of assist functions which can be displayed on a sub screen of the LCD. These include Waveform Monitor (WFM), Vector Scope and Zebra Patterns. High precision Flash Band Correction, Luminance adjustment and level horizon gauge.

Versatile Network Functions

Live Streaming

• Connect directly to Facebook or YouTube Live with support for RTMP (Real Time Messaging Protocol)
• Supports streaming distribution of RTMP-compatible content, such as live video distribution services
• Recording onto SD cards in the camera is also possible while streaming with modes below FHD
• Perfect for shooting sports events, concerts or ENG

3G-SDI/Ethernet

The 3G-SDI output terminal (BNC connector, 5CFV) can be used to transmit FHD 1080/60p, 1080/50p through a coaxial cable up to 100 m distant.

Built-in Ethernet

Avoid unstable WiFi with a Wired Internet connection using a LAN cable.

Read more about features and specifications in our .

Panasonic HC-X2 Camcorder Specifications

What’s in the Box

• Panasonic HC-X2 UHD 4K Professional Camcorder
• AC Adaptor
• AC Cable
• 5,900mAh Rechargeable Battery Pack
• Battery Charger
• New Microphone Holder
• Microphone Holder Screws
• Input Terminal Cap
• Eye Cup
• Lens Hood
